PREMIER-603D

Technical Specifications

• Input Voltage:230VAC, 50Hz
• Temperature Range:180°C - 480 °C (Soldering); :200°C - 500 °C (Hot- Air); Soldering Iron:24VAC, 50W
• Hot Air Gun:110 VAC,150 W
• Air Pump: 230 VAC, 3-24 Lt/min

System Includes

• Microprocessor Based Power Control Unit with Built-In Vacuum Pump
• Power Base with Built-In Air Pump & PID Based Power Control Channel with Digital Display
• Soldering Iron
• Hot Air Gun for Non-Contact Soldering and De-Soldering of SMD’s with Single Hole Nozzle
• Side Attachment for Hot Air Gun and Stand for Soldering Iron
• Microprocessor Based Power Control Unit with Built-In Vacuum Pump

Features

• Micro-Processor Based PID Control Auto Tuning Programmable Digital SMD/PTH Soldering.
• Optical Isolation with Zero Volt Switching.
• Closed Loop Temperature Control.
• Self-Contained Air Pump.
• SMT Tweezers for Quick Removal SMD Components [Optional at Extra Cost].
• Hot Air Gun for Safe and Non-Contact SMD Component Removal or Replacement [Built-In Vacuum Pick-Up is Optional at Extra Cost].
